Service Manual, 2017-02
11 / 36
3.5Change the door opening direction
1) Remove the hinge cover.
Unscrew screws.
Remove the upper hinge, Insert pins .
2) Remove the bottom door.
Unscrew screws and levelling feet.
Remove the lower hinge adjust feet
assembly.
3) Fix the levelling feet, lower hinge adjust feet
assembly and screws in the opposite side.
4) Place the up door.
Place and fix the the upper hinge. Fix the
hinge cover, Insert pins.
5) remove the screw hole cap, and use
screwdriver to remove the screws, then
dismantle the handle. Move the screw hole
cover on the other side of door onto this
screw hole
6) put the handle on proper position, aligning
with the screw hole, then fix it by screws, at
last to assemble the screw hole cap
