Midea V4 Plus User Manual

MCAC-VTSM-2016-04 R410A DC Inverter VRF V4 Plus W Series 50Hz
Specification & Performance 169
8. Functional parts and safety devices
Item
Symbol
Capacity
8HP
10HP
12HP
Compressor
Inverter
Inverter compressor
E655DHD-65D2YG
E655DHD-65D2YG
E655DHD-65D2YG
Safety
OLP
Current protection board
MDV-POWER-50A(IR341)-1
CCH
Crank case heater
DJRD-520A-1500-27.6W
Temperature
sensor
TSJ
Water inlet temp. of double-pipe
heat exchanger
B:4100，R(25℃)：10KΩ
TSC1
Water outlet temp. of upper pipe
B:4100，R(25℃)：10KΩ
TSC2
Water outlet temp. of lower pipe
B:4100，R(25℃)：10KΩ
T7
Discharge temp. sensor
B:3950,R(25℃):56104.8Ω
T5
Temp. sensor of inverter
module
B:3950,R(25℃):56104.8Ω
Pressure
sensor
HPS
High pressure sensor
(discharge)
Model: YLCGQ-NSK-BD046I-U289
0-5Mpa
LPS
Low pressure sensor
(suction)
YK-0.05/0.15-2000
0.05MPa
Functional
Parts
PMV
Electronic expansion valve
D32MISZ-1R
4.2MPa
4-W/V
4-way valve
STF-01VN1
SV
Solenoid valve
FDF6A-049-PK(ZB) or FDF6A11
4.2MPa

Midea V4 Plus Specifications
