Installation
44
Preparing the worktop
Make the worktop cut-out as shown
in "Building-in dimensions" or as
calculated (see "Installation of several
appliances"). Observe the safety
distances (see "Safety distances").
Wooden worktops
Seal the cut surfaces on wooden
worktops with a suitable sealant to
avoid swelling caused by moisture.
The sealant must be heat-resistant.
Make sure the sealant does not
come into contact with the top
surface of the worktop.
Position the spring clamps and
spacer bars on or at the top edge
of the cut-out in the positions shown.
Secure the spring clamps and
spacer bars with the 3.5x25mm
wood screws supplied.
