^ Use the screws supplied a to secure
the appliance to the worktop.
Fitting the plinth
To ensure trouble-free operation of
the appliance it is essential to fit the
original Miele ventilation grille.
^ Remove ventilation grille b by
pressing down the two lugs a and
simultaneously pulling the grille
forwards.
The plinth facing c can be fitted
without being altered in the following
situations:
It can be fitted unchanged if the
following dimensions are present:
Building-under
height
A
[mm]
Plinth facing
height
b
[mm]
820 100
870 150
Installing the appliance
34
