Building under
Where the building under height is
820 mm the appliance can be pushed
straight into the niche. Align the
appliance beforehand using the
adjustable feet.
Where the building under height is
870 mm the adjustable feet will first
have to be extended by approx. 50 mm
using a spanner (SW 30) or suitable
screwdriver. Then align the appliance.
^
Push the appliance into the niche
and then align it with neighbouring
furniture housing units.
^
Loosely secure the appliance to the
worktop through fixing bracket a.
The appliance is properly secured to
the worktop only after the plinth
depth has been adjusted and the
furniture door has been fitted to the
appliance.
Adjusting the plinth depth
^
Loosen screws a by turning them
approx. 8 to 10 times.
^
Align the plinth facia to neighbouring
furniture plinths.
^ Then tighten screws a until a
resistance is felt.
Building in the appliance
32
