When building in the appliance,
ensure that the vent outlets at the
front of the appliance are not
hindered, and that there is adequate
ventilation to the rear of the housing
unit by leaving a large enough gap
(see diagram: 16 mm x unit width).
Do not block the ventilation gaps
with any objects.
The appliance can fit into a 350 mm
high niche in a tall unit or a wall unit, or
a 360 mm high niche in a tall unit.
Building-in dimensions
M 8161
For safety reasons, do not build the
appliance into a wall unit that is
directly above a hob.
A minimum installation height of
850 mm must be maintained.
To transport the appliance, make
sure that you lift it by the appliance
housing and not by the frame. The
frame is not sturdy enough to bear
the weight of the appliance when it
is being carried.
Installation
53
20
372
595
16
600
>850
