MikroTik Chateau 5G User Manual

1.
2.
3.
4.
5.
6.
7.
8.
Reset button.
Powering DC jack 2.0 mm.
Five Gigabit ports, supporting automatic cross/straight cable correction (Auto MDI/X). Either straight or crossover cable can be used for
connecting to other network devices.
USB type-A.
SIM slot for Micro sim card.
Mode button.
Cover for external is not provided for models with antennas.SMA antenna connector
WPS Sync button.
Integrated Wireless module operating at 2.4 GHz, 802.11b/g/n protocol. Antenna gain 3 (dBi).
Integrated Wireless module operating at 5 GHz, 802.11a/n/ac protocol. Antenna gain 5.5 (dBi).
Mounting
The device is designed to be used indoors, by placing it on the desktop.
Powering
The device accepts power from an adapter:
Direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-28 V DC.
The power consumption under maximum load can reach 17 W, with attachments of 23 W.
Configuration
We recommend using Cat5 shielded cable. When using and installing this device please pay attention to the Maximum Permissible Exposure
(MPE) safety distance with a minimum of 20 cm between the radiator and your body.

MikroTik Chateau 5G Specifications

General

Operating temperature (T-T)	-40 - 70 °C
Certification	CE, EAC, ROHS
Mean time between failures (MTBF)	200000 h
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
DSL WAN	-
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channels quantity	4 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	2
Antenna gain level (max)	4 dBi
Product type	Tabletop router
Product color	Black, White
Sustainability certificates	RoHS
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	44 mm
Width	240 mm
Height	156 mm
