Milnor 30022H7J User Manual

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Parts List—Door Assembly
BMP920009/2001036V
(Sheet 2 of 2)
.
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A33 07100C *DRASSY(INDNT)LK,LOGO N4,5,6P
3015V7G/V7J;3022V7G/V7J
3015M4G/J/P,M6J,D4A
3022M5G/J
3022S4J,S4G,S5J
3015K4A,S4J,S5G,S5J
B A33 07100H DOOR ASY 3015/3020M4A 30015M4A+30020M4A
ONLY
C A33 06900F ASSY=DOOR W/MLOGO DKRED 3022 3022F8J/F8P/F8W
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 X2 02814C DOOR=SHELL W/1LOK-3020
all 2 02 02819 HINGE=STAMPED DOOR 25#
all 3 12P1AGHP1 HOLEPLUG 3/8"BLACK LPE
all 6 02 02817 FLANGE BRG=DOOR HINGE-NYLON
7 02 09215D DR GLASS=N4,5,6P W/MIL LOGO
B 7 02 09215A DORGLAS=DRAW W/MILNOR LOGO
C 7 02 09215E DOOR GLASS W/MIL LOGO (RED)
all 8 02 09021 RING=DOOR GLASS PRESSURE
all 9 02 02366 GASKET DOORGLAS GTR52-5220-3
all 10 02 10545 EXTR BAND-STAMPED SS CYLDOOR
all 11 02 10342A GASKET=15" DOOR
all 12 02 02764 HINGEPIN=SHELLDOOR L=10+5/8"
all 13 03 01420C DOOR STRIKER=ILOC
all 16 15G140 HXCPNT 1/4-20 #C250=20 NKLPLT
all 17 15K031 BUTSOKCAPSCR 1/4-20X1/2 SS18-8
all 18 15U181 LOCKWASHER MEDIUM 1/4 SS18-8
all 19 24G020N ROLLED WASH.252ID NYLTITE 25W
all 20 60C080 RECESS BUMPER RUBBERLAVELLE #7
all 21 15P103 TRDCUT-F RDHDSLOT 8-32UNCX1/2
all 22 15N173A FLTMACSCR 1/4-20 UNCX5/8 UCUTS
all 23 20C044 ADHESIVE 3M EC-1300 IN PINT CO
all 24 15Q077 SOKSETSCR 1/4-20X1/4 ZINC ALLE
all 25 03 01423C LATCH GUARD ILOC 3015-20
all 35 15U188 FLTWASH 1/4 STD COMM SS18-8
all 36 15N191 FLATMACHSCR 1/4-20X7/8 SS18-8
all 37 03 01420D DOOR HANDLE=ILOC 3015-20
A 30015V7J,T5J,T5E
3022V6J,T5J,T5E
A
