Milnor 30022H7J User Manual

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Parts List—Soap Chute Installation
BMP000040/2004055V
(Sheet 1 of 1)
. ---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A SA-33-058M 94000Z ASSY=PLSTC SOAP INLET
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------ all 1 02 03130 BRACKET=PLASTIC SOAP INLET all 2 02 03304D GASKET=SOAPCHUTE 1/8"EPDM BL all 3 02 03589I PLASTIC SHELLSIDE SOAP INLET all 4 02 03589T BACKING RING=PLSTC CHEM INLT all 5 02 03594 GUARD SOAP CHUTE=CWU all 6 02 03595 PIN SOAP CHUTE HINGE=CWU all 7 02 03630A SPLASH GUARD= SOAP CHUTE All 9 02 03593 89432B LID-SOAPCHUTE CWE TY304 SS all 10 15N133 RDMACSCR 10-24UNCZA X5/8" SS18 all 11 15U160 LOCKWASHER MEDIUM #10 SS18-8 all 12 15G130 HEXMACHSCRNUT 10-24UNC2 SS18-8 all 13 15P050 PHDCUT-F PANHD 10-32X3/4 SS410 all 14 24G018N ROLLED WASH.194ID NYLTITE 10W all 15 15P051 TRDFRM AB HOLTHD 10-16X3/4SS41
Soap Chute Installation 3010 & 3015 G5E,G5X 3010 & 3015CGE 30015V7J,T5J,T5E,C4A,C4T,C4E 30022V6J,T5J,T5E,C4A,C4T,C4E
HOUSING
GASKET
ITEMS 10,11&12 FASTEN SPLASH GUARD ASSEMBLY TO PLASTIC HOUSING (4 PLACES).
1
5
15
14
3
4
12
10
11
1
7
13
14
1
6
9
00A
2
SHELL

Milnor 30022H7J Specifications

General

Brand	Milnor
Model	30022H7J
Category	Washer
Language	English
