MHP30RM1AE/9541AV (1 of 1)
ABOUT THIS MANUAL
Scope
—This instruction manual is intended to provide preventive maintenance procedures, service proce-
dures, and mechanical parts identification for all Milnor
®
30015, 30020, and 30022 model rigid mount
washer-extractors. Measurements are in commonly used US and metric units unless otherwise noted.
See the appropriate programming, operating, and troubleshooting manual for information on the control
system. See the schematic manual for electrical parts identification and electrical troubleshooting.
Trademarks of Pellerin Milnor Corporation
—The following, some of which may be used in
this publication, are trademarks of Pellerin Milnor Corporation:
Ampsaver
®
Autolint
®
Auto-Purge
®
Autovac
CBW
®
Dye-Extractor
®
Dyextractor
®
E-P Plus
®
Gear Guardian
®
Hands-Off
®
Hydro-Cushion
®
Mildata
®
Milnet
®
Milnor
®
Miltrac
Miltron
Staph-Guard
®
System 4
®
System 7
®
Totaltrol
®
Manual Number/Date Code (When To Discard or Save)
—The manual number/date code
is located on the inside front cover, upper right corner just above the manual name. Whenever the manual is
reprinted with new information, part of this number changes. If the date code after the “/” changes, the new
version applies to all machines covered by the old version, but is improved— thus the old version can
be discarded. If the manual number before the “/” changes, the new manual covers only new machines.
Example: Discard MATMODELAE/8739
C
V when MATMODELAE/8739
D
V is received (minor improve-
ments). Also, discard MATMODELAE/87
39D
V when MATMODELAE/87
46A
V is received (major im-
provements). But keep MATMODEL
A
E/8746FV when MATMODEL
B
E/8815AV is received, since the
new manual no longer applies to machines originally shipped with the old manual.
Documents and Change Bars
—The individual documents comprising this manual use the same
revision criteria as the manual. Text documents also display change bars. Example: When section
MSOP0599AE/9135
B
V becomes MSOP0599AE/9135
C
V, change bars with the letter “C” appear next to all
changes for this revision. For a major rewrite (e.g., MSOP0599AE/92
26A
V), all change bars are deleted.
For Assistance
—Please call:
