26 Instruction Manual
Table 6. 7/16” and 5/8” Liquid Ends Assembly Drawing Location Reference Chart.
Drawing Location Reference Description
222 Plunger Assembly Consisting of:
222 Plunger
250 Thrust Washer (Ring)
245 Plunger Adapter
235 Nut, Floating Plunger
9001 Ball Check Cartridge Assembly Consisting of:
381 Body
383 Seat
382 O-Ring
385 Limit Pin
384 Ball Check
386 Ring Insert
419 Lantern Ring
418 Neck Ring
430 Gland Cap
250 Thrust Washer (Solid)
405 Liquid End
428 Liner, Gland Bearing
427 Gland Follower
280 Washer
270 Liquid End Bolts
435 Grease Fitting
425 Packing
