Under the bonnet
106
Important parts of the engine compartment
1 Battery, under the cover 125
2 Engine oil dipstick 106
3 Engine oil filler neck 107
4 Coolant expansion tank 107
5 Reservoir for washer fluid for the headlamp
and window washer system 45
6 Engine compartment fuse box 123
Engine oil
The engine oil consumption is dependent on
driving style and driving conditions.
Checking engine oil level
1. With the vehicle's engine at normal operat-
ing temperature, i.e. after uninterrupted
driving for at least 6 miles/10 km, park the
vehicle on a level surface.
2. Switch off the engine.
3. Pull the dipstick out after approx. 5 minutes
and wipe it off with a lint-free cloth, paper
towel or similar material.
4. Carefully push the dipstick all the way into
the guide tube and pull it out again.
The oil level should be between the two
marks on the dipstick.
The oil quantity corresponding to the difference
between the two marks on the dipstick is 1 US
quart/1 liter.
Do not fill beyond the upper mark on the
dipstick. Excess oil will damage the
engine.<
