PARTS LIST
ITEM QTY
PART
NUMBER
DESCRIPTION
1 1 2-100-204 ARMATURE SEMBLY 12V 3.25
2 1 788-015 R AINING RING
3 1 2-200-079 HOUSING SEMBLY CENTER 3.25 TXT
4 1 421-132 BRUSH END HOUSING SEMBLY 3.25
5 1 2-400-128 P IN END HOUSING SEMBLY 3.25
6 1 880-003 SEAL
7 1 880-006 SEAL W/SHIELD
8 1 140-010 BALL BEARING
9 2 188-052 BRUSH SEMBLY
11 1 2-600-285 BRUSH P TE W/HOLDER 3.25
12 2 975-032 COMPR SION SPRING
13 2 701-007 O-RING — THRU BOLT
14 1 701-039 O-RING
15 1 701-041 O-RING
16 2 830-001 SCREW — SELF THREAD #8-32X1.7
17 2 830-078 THRU BOLT #8-32X8.0
18 1 990-067 W HER — EEL THRU
19 1 990-070 W HER — NY TRON
20 1 144-049 F NGE BEARING (SERVICE ONLY)
21 1 2069239 MOTOR SEMBLY 12 V 3.25 VARIABLE SPD
22 1 2032046 36” COMPOSITE TUBE
n
1 1378121 PROPELLER KIT (INCLUD 23-26)
23 1 2061122 PROPELLER 3.25 HUB DIA
24 1 2151726 W HER — 5/16 D SS
25 1 2053101 NUT — PROP NYLOCK (MED) SS
26 1 2092600 DRIVE PIN
n
1 2771818 BRACK & HINGE SEMBLY (INCLUD 27-38)
n
1 2771910 BRACK SEMBLY (INCLUD 27, 29, 30)
*27 1 2061910 BRACK
28 1 2060510 HINGE PIN
ITEM QTY
PART
NUMBER
DESCRIPTION
*29 2 2061300 SCREW — C MP
*30 2 2011710 W HER — C MP SCREW
31 1 2063605 P TIC T-BAR
32 1 2062706 T-BAR SPRING
33 1 2067201 B CK TILT LEVER
34 1 2061810 P TIC HINGE
35 2 2037301 BUSHING HINGE
36 1 2062800 SNAP-IN TENSION BLOCK
37 1 2011385 SCREW — TENSION/KNOB
38 1 2060515 TILT LEVER PIN
39 1 2061520 DEPTH COL R
40 1 2011365 SCREW — COL R/NEW KNOB
41 1 2050609 LEADWIRE (WITH 10GA HD SPADE TERMINAL)
42 1 2062905 RAIN RELIEF
43 1 2256300 TIE WRAP
44 1 2994040 CONTROL BOX
45 1 2060225 CONTROL BOX COVER
46 1 2065715 DE L COVER ENDURA MAX 40
47 1 2065730 COVER DE L
48 1 2033401 SCREW — #10-24 X 1-3/4
49 1 2383124 NUT — 10-24 HEX
50 1 2061720 NYLON W HER
51 6 2012100 SCREW — #8-18 X 5/8
52 1 2990924 INNER HANDLE SEMBLY
53 1 2012104 SCREW — #6 X 1/2” SS
54 1 2990913 OUTER HANDLE SEMBLY
55 1 2060009 FRONT BEARING
56 1 2074070 BATTERY M ER 12V
57 1 2302742 D ENT SPRING - OFF
n
1 2883460 SEAL AND O-RING KIT (INCLUD 6-7, 13-15)
ENDURA MAX 40
40 LBS THRU - 12 VOLT - 36” SHA
n THIS ITEM IS PART OF AN SEMBLY.
*THIS ITEM IS PART OF A KIT AND ONLY LI ED FOR VIEWING PURPOS .
