Peripheral devices
14
INSTALLATION AND WIRING
2.1.2 Peripheral devices
Selecting the converter unit (FR-CC2-C)
Select the capacity of the FR-CC2-C converter unit according to the connected motor capacity.
The applicable motor capacity indicated is the maximum capacity applicable for use of the 4-pole standard motor.
Selecting the breaker/magnetic contactor
Check the model of the inverter and the converter unit you purchased. Appropriate peripheral devices must be selected
according to the capacity.
Refer to the table below to prepare appropriate peripheral devices.
• When the converter unit capacity is larger than the motor capacity, select an MCCB and a magnetic contactor according to
the converter unit model, and select cables and reactors according to the motor output.
• When the breaker on the converter unit's input side trips, check for the wiring fault (short circuit), damage to internal parts of
the inverter and the converter unit, etc. The cause of the trip must be identified and removed before turning ON the power of
the breaker.
Converter unit
FR-CC2-[ ]
Inverter
Model
FR-F862-[ ]
Rated current
(A)
Motor capacity
(kW)
C355K 05450
SLD 545 400
LD 496 355
C400K 06470
SLD 647 450
LD 589 400
C560K 08500
SLD 850 630
LD 773 560
Motor
output
(kW)
Applicable converter
model
Applicable inverter
model
Molded case circuit breaker (MCCB)
or
earth leakage circuit breaker (ELB)
(NF, NV type)
Input-side
magnetic
contactor
SLD LD SLD LD
400 FR-CC2-C355K FR-F862-05450 700 A 700 A 475 A 469 A
450 FR-CC2-C400K FR-F862-06470 900 A 800 A 592 A 589 A
630 FR-CC2-C560K FR-F862-08500 1200 A 1000 A 776 A 773 A
Assumes the use of a 4-pole standard motor with the power supply voltage of 575 VAC 50 Hz.
Select an MCCB according to the power supply capacity.
Install one MCCB per converter.
For the use in the United States or Canada, provide the appropriate UL and cUL listed fuse that
is suitable for branch circuit protection. (Refer to page 83.)
The magnetic contactor is selected based on the AC-1 class. The electrical durability of magnetic contactor is 500,000 times. When the
magnetic contactor is used for emergency stops during motor driving, the electrical durability is 25 times.
If using an MC for emergency stop during driving the motor, select an MC regarding the converter unit input side current as JEM1038-AC-3 class
rated current. When using an MC on the inverter output side for commercial-power supply operation switching using a general-purpose motor,
select an MC regarding the rated motor current as JEM1038-AC-3 class rated current.
MCCB Converter unit
MCCB Converter unit
M
M
INV
INV
