GB-8

150 150

300

<ATWindoorunit>

(2)TurnonthebreakeroftheroomairconditionerortheATWunitandcheck

thattheLEDindicationoftheWi-Fiinterfaceenterstheinitialstateshownon

right.

Mountinthesameprocedureforroomairconditioner.Pleasereferto“Whenmountingonthewall”

onpage6.

Settingup

RefertoSETUPQUICKREFERENCEGUIDE(Includedinsamepackage)andSETUPMANUALto

connecttoaRouterforsettingup.

ForSETUPMANUAL,pleasegotothewebsitebelow.

ForMELCloudUserManual,pleasegotothewebsitebelow.

InitialState

ERR OFF

NET OFF

MODE OFF

UNIT Flashing

5. Specications

InputVoltage DC12.7V(fromindoorunit)

Powerconsumption MAX2W

SizeH×W×D(mm) 79×44×18.5

Weight(g) 110(includingcable)

Transmitterpowerlevel(MAX) 17.5dBm@IEEE802.11b

RFchannel 1ch~13ch(2412~2472MHz)

Radioprotocol IEEE802.11b/g/n(20)

Encryption AES

Authentication WPA2-PSK

SoftwareVer XX.00

Lengthofcable(mm) 2,040

ForDeclarationofConformity,pleasegotothewebsitebelow.

Cylinder unit Hydrobox

Connecting to Cylinder unit Connecting to Hydrobox

Screw3

Mounting

cordclamp4

Mounting

cordclamp4

JG79Y198H01_01_en.indd 8 11/24/2016 10:35:10 AM
