● OPERATING INSTRUCTIONS ●
EN
EN-17
DB: Dry Bulb
WB: Wet Bulb
Indoor
Outdoor
MUZ-AP25/35/42/50VG MUZ-AP25/35/42/50VGH
Cooling
Upper limit
32°C DB
23°C WB
46°C DB
—
46°C DB
—
Lower limit
21°C DB
15°C WB
-10°C DB
—
-10°C DB
—
Heating
Upper limit
27°C DB
—
24°C DB
18°C WB
24°C DB
18°C WB
Lower limit
20°C DB
—
-15°C DB
-16°C WB
-20°C DB
-21°C WB
Note:
Rating condition
Cooling — Indoor: 27°C DB, 19°C WB
Outdoor: 35°C DB
Heating — Indoor: 20°C DB
Outdoor: 7°C DB, 6°C WB
Guaranteed operating range
SPECIFICATIONS
Wi-Fi interface
Model MAC-566IFB-E MAC-577IF2-E
Input Voltage DC12.7 V (from indoor unit)
Power consumption MAX. 2 W
Size H×W×D (mm) 79×44×18.5 73.5×41.5×18.5
Weight (g) (including cable) 60 46
Transmitter power level (MAX.)
17.5 dBm
@IEEE 802.11b
20 dBm
@IEEE 802.11b
RF channel 1ch ~ 13ch (2412~2472 MHz)
Radio protocol IEEE 802.11b/g/n (20)
Encryption AES
Authentication WPA2-PSK
Software Version XX.00
For Declaration of Conformity, please go to the website below.
http://www.melcloud.com/Support
Model
Indoor MSZ-AP25VG(K) MSZ-AP35VG(K) MSZ-AP42VG(K) MSZ-AP50VG(K)
Outdoor MUZ-AP25VG(H) MUZ-AP35VG(H) MUZ-AP42VG(H) MUZ-AP50VG(H)
Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating
Power supply ~ /N, 230 V, 50 Hz
Capacity kW 2.5 3.2 3.5 4.0 4.2 5.4 5.0 5.8
Input kW 0.60 0.78 0.99 1.03 1.30 1.49 1.55 1.60
Weight
Indoor kg 10.5
Outdoor kg 31 31 35 40
Refrigerant fi lling capacity (R32) kg 0.55 0.55 0.70 1.00
IP code
Indoor IP 20
Outdoor IP 24
Permissible excessive
operating pressure
LP ps MPa 2.77
HP ps MPa 4.17
Noise level (SPL)
Indoor (Super High/
High/Med./Low/Silent)
dB(A)
42/36/30/
24/19
45/39/34/
24/19
42/36/30/
24/19
45/38/31/
24/19
42/38/34/
29/21
45/40/35/
29/21
44/40/36/
33/28
48/43/38/
33/28
Outdoor dB(A) 47 48 49 50 50 51 52 52
