Unit: mm
Piping
Insulation ø37 O.D
Liquid line ø6.35 - 0.5 m (Flared connection ø6.35)
Gas line
ø9.52 - 0.43 m
(Flared connection: ø9.52 (18/22/25/35/42), ø12.7 (50))
Drain hose Insulation ø28 O.D Connected part ø16 O.D
OUTLINES AND DIMENSIONS
5
MSZ-EF18VEW MSZ-EF22VEW MSZ-EF25VEW MSZ-EF35VEW MSZ-EF42VEW MSZ-EF50VEW
MSZ-EF18VEB MSZ-EF22VEB MSZ-EF25VEB MSZ-EF35VEB MSZ-EF42VEB MSZ-EF50VEB
MSZ-EF18VES MSZ-EF22VES MSZ-EF25VES MSZ-EF35VES MSZ-EF42VES MSZ-EF50VES
OBH589G
