Mitsubishi Electric PAR-31MAA Information Sheet

EASY OPERATION
Backlit LCD (Liquid Crystal Display)
Full dot backlit LCD makes it easy to see and control units.
Large, easy-to-see display
Full-dot LCD display with large characters for easy viewing
Contrast also adjustable
Simple button arrangement
Buttons are arranged according to usage to allow for intuitive navigation.
Frequently used buttons are larger than other buttons to prevent unintended use.
New MA remote controller PAR-31MAA
Ideal remote controller in pursuit of easy operation, convenience, and energy saving
CONVENIENCE
Night Setback
To prevent indoor dew or excessive temperature rise, this control starts heating operation
when the control object group is stopped and the room temperature drops below the preset
lower limit temperature. Also, this control starts cooling operation when the control object
group is stopped and the room temperature rises above the preset upper limit temperature.
ENERGY SAVING
Auto Return
This function helps to maintain the indoor temperature at the required level. Even if the
temperature setting is changed during operation, the set temperature automatically returns
to the originally preset temperature after certain amount of time. It is possible to set the
required temperature for limited time (30-120 min. in 10-minute increments).
<Sample screens when the Auto return function is enabled>
Example: Lower the Set temp. to 24°C. 60 minutes later, the Set temp. will be back to 28°C.
Functions
[Basic Functions]
▪ ON/OFF ▪ Operation mode switching ▪ Room temperature setting/display ▪ Fan speed setting
▪ Vane setting▪ Louver setting▪ Clock setting/display▪ Filter information display
Heating
Cooling
Room temp.
21°C
Upper limit temp.
28°C
Lower limit temp.
12°C
Room temp.
24°C
Night setback operation
Heating
ON
Heating
OFF
Cooling
ON
Night setback operation
Cooling
OFF
Setback control time Setback control time
Setback operation starts
when the indoor
temperature drops below
the lower limit during
setback control time.
Setback operation
stops
-when the indoor
temperature rises 3°C
above the lower limit
OR
-when the control time
is over
Setback operation starts
when the temperature
exceeds the upper limit
during setback control time.
Setback operation stops
-when the temperature
drops -3°C below the
upper limit
OR
-when the control time is
over
Fri Fri Fri
The Set temp. is
changed from 28ºC
to 24ºC by a user.
60 minutes later,
the Set temp.
returns to 28ºC
automatically.
Cool
AutoSet temp.
Mode Fan
Cool
AutoSet temp.
Mode Fan
Cool
AutoSet temp.
Mode Fan
Temp. Temp. Temp.
60 minutes later
Language to be displayed on the screen can be selected from eight languages: English, French, German, Spanish, Italian,
Portuguese, Swedish, and Russian.
Screen contrast can be adjusted.
The lower limit and the upper limit of the settable temperature in each operation mode can be limited.
Manual vane angle
The vane angle can be set to a fixed position. * Valid only for the indoor units that are compatible with this function.
Display mode switching
Error information
Ventilation equipment
control
Timer
High power
Language
selection
Contrast
Administrator password (required for schedule setting) and Maintenance password (required for test run and function
setting) can be set.
On/Off timer: The unit automatically turns on or off at the preset time.
• Time can be set in 5-minute increments.
• It is possible to set only the time when the unit turns on or when the unit turns off.
Auto-Off timer: The unit automatically stops after the preset time has elapsed.
• Time can be set to a value from 30 to 240 in 10-minute increments.
The units operate at higher-than-normal capacity for up to 30 minutes.
OU silent mode
Energy saving
It´s available to set the time periods in which priority is given to quiet operation of outdoor units over temperature control.
• Start/stop time can be set in 5-minute increments.
• Select the desired silent level from "Normal", "Middle", and "Quiet".
The start/stop times to operate the units in the energy-save mode for each day of the week, and the energy-saving rate
can be set.
• Up to four energy-save operation patterns can be set for each day.
• Time can be set in 5-minute increments.
• Energy-saving rate can be set to a value from 0% and 50 to 90% in 10% increments.
Auto descending panel
Interlock settings and interlock operation settings for Lossnay units can be made.
OFF/High/Low can be switched.
Error code, error unit, unit address, unit model, serial number, contact information (dealer's phone number) can be displayed.
* The unit model, serial number, and contact information need to be registered in advance to be displayed.
* The unit address may not be displayed depending on the error type.
The main display can be displayed in two different modes: "Full" and "Basic".
Password
Temperature range
restriction
Operation lock
Weekly timer
The automatic descending panel can be operated. * Valid only for the indoor units that are compatible with this function.
Settings including ON/OFF, Operation mode, Set temp. and Vane can be locked.
ON/OFF and temperature setting can be scheduled for each day.
• Up to eight operation patterns can be set for each day.
• Time can be set in 5-minute increments.
* Not valid when the On/Off timer is enabled.
Mr. Slim only
Mr. Slim only
Mr. Slim only
[Advanced Functions]
[New Functions]
▪ Set temperature can be set by 0.5
°C increment.(City Multi and Mr.Slim)
▪ Room temperature can be shown by 0.5
°C increment.(City Multi and Mr.Slim)
▪ Dual set temperature available* (City Multi)
*Note: Dual set temperature is only available with City Multi new indoor units that have dual set temperature capabilities.

Mitsubishi Electric PAR-31MAA Specifications

General

Brand	Mitsubishi Electric
Model	PAR-31MAA
Category	Remote Control
Language	English
