5-1. REFILLING REFRIGERANT CHARGE (R32: kg) PUZ-M200/250
AVB52FBAMT
Service Ref.
Compressor model
(Winding temperature at 20°C)
U-V
U-W
W-V
Winding
Resistance
( " )
0.305
0.305
0.305
PUZ-M200YKA.UK
PUZ-M250YKA.UK
Additional charge is required for pipes longer
than 30 m.
Service Ref.
Piping length (one way)
Initial
charged
10 m 20 m 30 m 40 m 50 m 60 m 75 m
PUZ-M200YKA.UK 5.1 5.4 5.6 +0.4 (6.0) +0.8 (6.4) +1.2 (6.8) +1.6 (7.2) 5.6
PUZ-M250YKA.UK 6.2 6.5 6.8 +0.6 (7.4) +1.2 (8.0) +1.8 (8.6) +2.4 (9.2) 6.8
5-3. COMPRESSOR TECHNICAL DATA
5-2. ADJUSTING THE AMOUNT OF REFRIGERANT PUZ-M200/250
Service Ref.
Initial
charged
Amount of additional refrigerant charge (kg)
31–40 m and less 41–50 m and less 51–60 m and less 61–70 m and less
PUZ-M200YKA.UK 5.6 0.4 0.8 1.2 1.6
PUZ-M250YKA.UK 6.8 0.6 1.2 1.8 2.4
