81
OCH737
(2) Functions available when setting the unit number to 01–03 or AL (07 in the case of wireless remote controller)
• When setting functions for an indoor unit in an independent system, set the unit number to 01 referring to 4 setting the
indoor unit number of Operating Procedure.
• When setting functions for a simultaneous- Twin Triple indoor unit system, set the unit number to 01 to 03 for each indoor
unit in the case of selecting different functions for each unit referring to 4 setting the indoor unit number of Operating Procedure.
• When setting the same functions for an entire simultaneous Twin Triple-indoor unit system, set refrigerant address to AL (07
in the case of wireless remote controller) referring to 4 setting the indoor unit number of Operating Procedure.
PEAD-M
•
JA(L)
Function Settings
No.
Mode
No.
Setting
: Initial setting
(
Factory setting
)
Filter sign 100h 1
2500h 07 2
No filter sign indicator
3
External static pressure
35/50/70/100/150Pa
08
10
1
2
Extra low
3
Fan speed during the
heating thermo OFF
Stop
25
1
Set fan speed
2
27
1
2
Detection of abnormality
of the pipe
1
28
2
Set temperature in heating
24
mode
(
4 degree-up
)
Refer to the right table
External static pressure
35/50/70/100/150Pa
Refer to the right table
Available
Not available
Fan speed during the
cooling thermo OFF
Set fan speed
Stop
Available
Not available
External static
pressure
Setting No.
Initial setting
(
Factory setting
)
35Pa
50Pa
70Pa
100Pa
150Pa
2
3
1
2
3
Mode No. 08 Mode No. 10
1
1
2
2
2
Mode No.11
Setting No. Settings PLA-RP•EA PCA-M•KA
1
No Vanes
Vane No.3 setting
(
Downward position than the standard
)
Less smudging
No vane function
2 Vane No.1 setting Standard Standard
3 Vane No.2 setting
Less draft *
(Upward position than the standard)
Less draft *
(Upward position than the standard)
* In this setting, the ceiling may be smudged.
Function Settings
Mode
No.
Setting
No.
Initial setting (factory setting) ─: Not available
4-way cassette Ceiling suspended Wall mounted
PLA-RP•EA PCA-HAQ PCA-M•KA PKA-M•HA(L) PKA-M•KA(L)
Filter sign
100 h
07
1 ● ● ●
2500 h 2 ● ●
No lter sign indicator 3
Airow
(Fan speed)
Quiet
08
1 – –
Standard 2 ● – ● ● ●
High ceiling 3 – –
No. of air outlets
4 directions
09
1 ● – – – –
3 directions 2 – – – –
2 directions 3 – – – –
Optional high e󰀩ciency
lter
Not supported
10
1 ● – ● – –
Supported 2 – – –
Vane setting
No vanes (Vane No. 3 setting: PLA only)
11
1 – – –
Vane No.1 setting 2 – ● – –
Vane No.2 setting 3 ● – – –
3D i-See sensor
positioning
Position
1
("□" stamp position)
12
1 – – – –
(Position
2
) 2 – – – –
Position
3
("□" stamp position) 3 ● – – – –
Optional humidier
(PLA only)
Not supported
13
1 ● – – – –
Supported 2 – – – – –
Vane di󰀨erential setting in
heating mode
(cold wind prevention)
No.1 setting (TH5: 24–28
:
)
14
1 –
No.2 setting (Standard, TH5: 28–32
:
) 2 ● – ● ● ●
No.3 setting (TH5: 32–38
:
) 3 –
Swing
Not available Swing
23
1
Available
Wave airow 2 ● – ● ● ●
Set temperature in heating
mode (4 degree-up)*
Available
24
1 ● ● ● ● ●
Not available 2
Fan speed during the
heating thermo-OFF
Extra low
25
1 ● ● ● ● ●
Stop 2
Setting fan speed 3
3D i-See sensor ceiling
height setting
Low ceiling
26
1 – – – –
Standard 2 – – – –
High ceiling 3 ● – – – –
Fan speed during the
cooling thermo-OFF
Setting fan speed
27
1 ●
Stop 2
Extra low 3 ● – ● ● ●
Detection of abnormality of
the pipe temperature
(P8)
Available
28
1 ● ● ● ● ●
Not available 2
*PKA-HA/KA: 2 degree-up
}
PLA-EA
