(8) Effective range of cool/hot wind (Reference)
(a) FDT series
Guideline for ceiling height
Fan Speed Setting
Model
FDT40VF50VF60VF FDT71VF FDT100VF FDT125VF,140VF
Hi 2.7m 3.0m 3.2m 3.6m
PHi 3.5m 3.8m 4.3m 4.5m
Notes (1) If the ceiling height is over 3m, please consider to add circulators.
This table shows reference values in case of four outlet.
If you shut some outlets, they are different.
Fan speed setting can be changed by using a wired remote controller.
(b) FDEN series
Model Effective range
FDEN40VF, 50VF 7.5m
FDEN60VF, 71VF 8.0m
FDEN100VF, 125VF, 140VF 9.0m
[Conditions] 1.
Heightofunit:2.4–3.0(m)aboveoorlevel
2. Fan speed : Hi
3. Location: Free space without obstacles
4.
Theeffectiverangemeansthehorizontaldistanceforthewindtoreachtheoor.
5. Wind speed at the effective range: 0.5 m/s
(c) FDF series
Model Effective range
FDF71VD 5m
FDF100VD, 125VD, 140VD 8m
[Conditions] 1. Fan speed : Hi
2. Location: Free space without obstacles
3.
Theeffectiverangemeansthehorizontaldistanceforthewindtoreachtheoor.
4. Wind speed at the effective range: 0.5 m/s
