Mitsubishi Heavy Industries SCM45ZJ-S User Manual

-
7
-
'10 • SCM-SM-094
Model SRK20~50ZJ-S
3D AUTO light (green)
Illuminates during 3D AUTO operation.
HI POWER light (green)
Illuminates during HIGH POWER operation.
TIMER light (yellow)
Illuminates during TIMER operation.
This button can be used for turning on/off the unit when remote
control is not available.
Remote control signal receiver
Unit ON/OFF button
RUN (HOT KEEP) light (green)
Illuminates during operation.
Blinks when airflow stops due to the HOT
KEEP and CLEAN operation .
ON
OFF
1.5 sec.
0.5 sec.
HOT KEEP
3 sec.
1 sec.
ON
OFF
CLEAN operation
Model SRF25~50ZJX-S
Unit display section
AIR SELECTION button
AIR OUTLET SELECTION light (green)
Illuminates during upper air outlet operation.
TIMER light (yellow)
Illuminates during TIMER operation.
This button can be used for turning on/off the unit when remote
controller is not available.
HI POWER Light (green)
Illuminates during HIGH POWER operation.
Unit ON/OFF button
Model All models
RUN (HOT KEEP) light (green)
• Illuminates during operation.
•
Blinks when airflow stops due to the ‘HOT
KEEP’
and ‘ CLEAN operation ’.
Remote controller signal receiver
1.5 sec.
ON
OFF
0.5 sec.
HOT KEEP
3 sec.
1 sec.
ON
OFF
CLEAN operation
ECONO light (green)
Illuminates during ECONOMY operation.
Use this button to switch between the combination of upper and
lower air outlets and upper air outlet.
