Mitsubishi Heavy Industries SRK20HC-S User Manual

-
7
-
2.4 Piping system
Models SRK20HC-S, 28HC-S, 40HC-S
Outdoor unitIndoor unit
Room temp.
thermistor
Heat
exchanger
Flare connecting
Heat
exchanger
thermistor
Piping
(Liquid)
ø6.35
Check joint
4 way valve
Service valve (Liquid)
Flare connecting
Discharge temp.
thermistor
Cooling cycle
Heating cycle
Outdoor air
temp. thermistor
Heat
exchanger
Heat exchanger
thermistor
Compressor
Capillary tube
Strainer
Accumulator
Service valve
(Gas)
Capillary tube
Electronic
expansion valve
( )
Piping
(Gas)
20, 28 : ø9.52
40 : ø12.7

Mitsubishi Heavy Industries SRK20HC-S Specifications

General

Brand	Mitsubishi Heavy Industries
Model	SRK20HC-S
Category	Room air conditioners
Language	English
