7-44
Vehicle care and maintenance
7
2.4 liter models
*: Fusible link
Some fuses may not be installed on your vehicle, depend-
ing on the vehicle model or specifications.
The table above shows the main equipment corresponding
to each fuse.
Identification of fuse
N00901100049
No. Symbol Electrical system Capacity
1 Condenser fan motor 20 A*
Engine compartment fuse location
Front
Capacity Color
7.5 A Brown
10 A Red
15 A Blue
20 A Yellow (fuse type) / Light blue (fusible link type)
30 A Green (fuse type) / Pink (fusible link type)
40 A Green
50 A Red
60 A Yellow
80 A White
