Mitsubishi FR-S520S-0.2K to 1.5K-EC(R) User Manual

44
9. OUTLINE DRAWINGS
0.1K, 0.2K, 0.4K, 0.75K
φ
5 hole
68 (2.68)
6 (0.24)
56 (2.20)
6 (0.24)
5 (0.20)
128 (5.04)
5 (0.20)
118 (4.65)
-+
5 (0.20)
18.5
(0.73)
D1
4 (0.16)
D2
D
Rating
plate
Capacity
0.1K, 0.2K
0.4K
0.75K
132.5 (5.22)
112.5 (4.43)
80.5 (3.17)
D
·3-phase 200V power supply
62 (2.44)
42 (1.65)
10 (0.39)
D1
52 (2.05)
52 (2.05)
52 (2.05)
D2
Capacity
0.1K, 0.2K
0.4K
0.75K
162.5 (6.40)
142.5 (5.61)
80.5 (3.17)
D
·Single-phase 200V power supply
62 (2.44)
42 (1.65)
10 (0.39)
D1
82 (3.23)
82 (3.23)
52 (2.05)
D2
(Unit: mm (inches))
