MDS-A-SVJ
1OOV Servo Amps
4.4
1OOV Servo Amps
A low power supply voltage can limit maximum operating capacity.
The MDS-A-SVJ-OIW (1OOW) and MDS-A-SVJ-03W (300W) normally have an
instantaneous operating capacity of 300% of the rated motor output
(excluding HA**N motors).
If the power supply voltage is below 9OV,
however,
the MDS-A-SVJ-03W's maximum instantaneous operating capacity
is limited to 4.75A (250% of the HA-FE33's rated output). With this
limitation, excessive error 1 (ODl) alarms are liable to occur. To
prevent excessive error 1 alarms,
increase the excessive error detec-
tion range settings (SV023 and SV053).
Note that the MIX-A-SVJ-OlW (1OOW) is not thus affected.
c<NOTE>>The MDS-A-SVJ-OlW and MDS-A-SVJ-03W are designed for use with a
single-phase, 1OOV power supply.
Never apply a 2OOV power sup-
ply. Use of a
200V power supply would damage the amp.
- 26 -
BNP-B3882B
