8
-
Item
Model
SCM80ZD-S
Cooling capacity W 8000 (1000~9300)
Heating capacity W 9500 (850~9700)
Power source 1 Phase 220/230/240V 50Hz
Power consumption
Cooling
W
2650 (350~3200)
Heating 2440 (300~3200)
Running current
Cooling 12.2/11.6/11.2
Heating
A
11.2/10.7/10.3
Sound level
Cooling : 51/51/52 Heating : 52/52/53
Noise level
Power level
dB
Cooling : 65/65/66 Heating : 66/66/67
Exterior dimensions
Height × Width × Depth
mm
845 × 880 × 340
Color Polar white
Net weight kg 66
Refrigerant equipment
Compressor type & Q’ty
TNB220FLBM1 [Twin rotary type]
×
1
Motor kW 1.3
Starting method Direct start
Refrigerant control Capillary tubes + Electronic expansion valve
Refrigerant kg R410A 3.05 (Pre-charged up to the piping length of 40m)
Refrigerant oil R 0.67 (MEL56)
Air handling equipment
Fan type & Q’ty
Propeller fan × 1
Motor W 55
Air flow (at high) CMM 56
Shock & vibration absorber Rubber (for compressor)
Safety equipment
Size × Core × Number mm (in)
Liquid line: φ 6.35 (1/4″) × 4
Gas line: φ 9.52 (3/8″) × 4
Connecting method Flare connecting
Attached length piping —
Insulation Necessary (Both Liquid & Gas lines)
Power source supply Terminal block (Screw fixing type)
Size × Core number 1.5 mm
2
× 4 cores (Including earth cable) × 4
Connecting method Terminal block (Screw fixing type)
Accessories (included)
Union : (φ 9.52 / φ 12.7) × 2
Installation sheet, Manual instruction
SKM22, 25, 28, 35, 50 type
Indoor units to be combined STM25, 35, 50, 60 type
SRRM25, 35, 50, 60 type
Model SCM80ZD-S
Compressor overheat protection, Overcurrent protection
Serial signal error protection
Notes (1) The data are measured at the following conditions.
Refrigerant
piping
Connection
wiring
Item Indoor air temperature Outdoor air temperature
Standards
Operation DB WB DB WB
Cooling 27ºC 19ºC 35ºC 24ºC ISO-T1, JIS C9612
Heating 20ºC – 7ºC 6ºC ISO-T1, JIS C9612
(2) The values for capacity and power consumption shown in a range ( ) indicate the minimum and maximum of the range.
(3) If the piping length exceeds 40 m, additional charging is required. (20g/m)
