2
-
1.2 How to read the model name
Example : SR K 10 C FV -4
TIMER lightRUN light
1 GENERAL INFORMATION
1.1 Specific features
The “MITSUBISHI HEAVY INDUSTRIES, LTD.” room air-conditioner: SRK series are of split and wall mounted type and the unit
consists of indoor unit and outdoor unit with refrigerant precharged in factory. The indoor unit is composed of room air cooling equip-
ment with operation control switch and the outdoor unit is composed of condensing unit with compressor.
(1) Remote control flap & louver
The flap & louver can be automatically controlled by operating wireless remote control.
¡ Flap swing : The flaps swing up and down successively.
¡ Louver swing : The louvers swing left and right successively.
¡ 3D auto operation : Fan speed and air flow direction are automatically controlled, allowing the entire room to be
efficiently conditioned.
¡ Memory flap : Once the flap & louver position is set, the unit memorizes the position and continues to operate
at the same position from the next time.
(2) Automatic operation
When the remote control switch is set on “auto(
) ”, it will either automatically decide operation mode such as cooling and
thermal dry, or operate in the operation mode before it has been turned to automatic control.
(3) Self diagnosis function
¡ We are constantly trying to do better service to our customers by installing such judges that show abnormality of operation as
follows.
Room temperature sensor error
Indoor fan motor error
Heat exchanger sensor error
2 time flash
6 time flash
TIMER light
ON
Trouble of outdoor unit
2 time flash
RUN light
ON
For Asia
Series No.
Cooling only type
Product capacity
Wall mounted type
Split type room air-conditioner
1 time flash
To Next Page
