Appendices 65
Outputs
Video 1
RCA Pin Plug 1.0 Vp-p, 75-ohm
Signal Type: NTSC 480i only
Audio (Signal) 2 pairs
RCA Pin Plug, 500 mV rms
+
200 mV (full scale) for analog sources
1.5 Vrms
+
0.5 Vrms (full scale) for digital sources.
Audio (Speakers) 2 10 watt, 5.5" x 2.2"
Digital Audio Output 1 RCA Pin Plug, Signal Type, Dolby Digital, PCM
Physical Characteristics and Power Consumption
Models
Dimensions (inches)
Weight (lbs.)
Power
Consumption
Height Width Depth
WD-52526 34” 49.6 17.8 114 225 watts
WD-62526 40.5 58.3 19.9 133 225 watts
Appendix C: Specifications, continued
The HDMI input is compliant with EIA-861B standards for standard, extended, and high-definition video; digital
audio, and HDCP copy protection. The HDMI input is not intended for use with personal computers or devices
outputting video signals with computer resolutions.
