Mitsubishi XD3500U User Manual

EN-50
Specifi cations
The specifi cations and outside appearance of the projector are subject to change without prior notice.
Type DLP™ projector
Model XD3500U
Display technology 0.7-inch Single chip DMD
Pixel 1024 x 768 = 786432 pixels
Projection lens F 2.0 - 2.4 f= 24.5 - 33.1 mm
Light-source lamp 330 W
Image size (projection distance) 40” min. to 300” max. (projection distance 1.4 to 10.6 m)
Maximum resolution Computer signal Maximum resolution: 1600 x 1200 dots (compressed)
Panel resolution: 1024 x 768 dots
Video signal NTSC/PAL/SECAM/4.43NTSC/PAL-M/PAL-N/PAL-60
Component signal 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Panel resolution: 1024 x 768 dots
Computer/component video input [Signal type] [Terminal type] [Line]
Analog RGB Mini D-SUB 15-pin 1
Analog RGB 5 BNC 1
Digital RGB DVI-D 24-pin 1
Video input [Signal type] [Terminal type] [Line]
Video input RCA / BNC 1
S-video input S / 2 BNC 1
Audio input [Signal type] [Terminal type] [Line]
RGB/Component Stereo mini jack (ø3.5) 2
Digital RGB Stereo mini jack (ø3.5) 1
Video RCA (L, R) 1
S-video RCA (L, R) 1
HDMI input [Signal type] [Terminal type] [Line]
HDMI HDMI 19-pin 1
Monitor output [Signal type] [Terminal type] [Line]
Analog RGB Mini D-SUB 15-pin 1
Audio output [Signal type] [Terminal type] [Line]
RGB/Component Stereo mini jack (ø3.5) 1
Speaker 10 W Mono Round type ø4.5 cm x 1
Control terminal/others RS-232C (D-SUB 9-pin), USB, LAN (RJ-45), REMOTE IN/OUT
Operating temperatures +41°F (+5°C) to +95°F (+35°C)
Rated voltage AC 100 - 240 V, 50/60 Hz
Power consumption 4.5 A, 430 W
During standby:
AC 100 - 120 V: 2 W (when STANDBY MODE is STANDARD)
0.4 W (when STANDBY MODE is LOW)
AC 220 - 240 V: 2 W (when STANDBY MODE is STANDARD)
0.6 W (when STANDBY MODE is LOW)
Dimensions (not including protrusion) 450 mm (W) x 187 mm (H) x 373 mm (D) (projector only)
450 mm (W) x 187 mm (H) x 468 mm (D) (including the terminal cover)
Weight 10.3 kg (projector only), 10.5 kg (including the terminal cover)
Others S-video input Luminance signal: Vp-p=1.0 V 75 Ω (negative sync)
Chrominance signals: Vp-p=0.286 V 75 Ω (burst signal)
Video input Vp-p=1.0 V 75 Ω (negative sync)
Component video
input
YC
B
C
R
: Vp-p=1.0 V 75 Ω (Y) (negative sync)
Vp-p=0.7 V 75 Ω (C
B
, C
R
)
Analog input RGB: Vp-p=0.7 V 75 Ω (negative sync)
YC
B
C
R
: Vp-p=1.0 V (Y) (negative sync) Vp-p=0.7 V (C
B
, C
R
)
HD/CS: TTL-level (negative or positive polarity)
VD: TTL-level (negative or positive polarity)
Digital input (DVI) DVI-D interface (TMDS single link) with HDCP
Digital input (HDMI) HDMI interface (TMDS single link) (Only PCM audio is supported.)
Audio input 350 mVrms, 10 kΩ or more
DC OUT 5 V 1.5 A (max)
Replacement part (option/not included in the box)
Spare lamp: VLT-XD3200LP
Option lenses: OL-XD2000SZ, OL-XD2000LZ, OL-XD2000TZ, OL-XD2000FR
