Preparing Your Radio for Use
English
Turning On the Radio
Press the Power On/Off Button
briefly to power on the radio.
After a short time, the red, yellow
and green LEDs light up. The
display then shows Zone and
channel text, and menu items
display on the screen.
The backlight will turn on to the last selected dim level.
Note: Pressing the Power On/Off Button before the LED
lights up will be ignored.
If FAIL ##/## appears in the display, the radio will not
function until the condition has been corrected.
If ERROR ##/## appears, some non-critical data has
been changed. If either of these displays appear, if the
display goes blank, or if the unit appears to be locked
up, see Helpful Tips on page 111 for more
information.
If CH MISMATCH appears, means that either the
Control Head has been connected to an incompatible
transceiver, or vice versa.
To turn off the radio, press the Power On/Off Button after the
LEDs light up.
Validating Compatibility During Power Up
The radio validates and updates the software and hardware of
your control head(s) during power up. Follow the procedure
below when your radio runs this task.
Procedure:
1 The display shows MAINTENANCE MODE REMOTE DEVICE;
promptly followed by other maintenance statuses.
2 The display shows UPDATE DONE PLEASE RESET upon
completion.
OR
The display shows UPDATE FAILED PLEASE RESET when it
fails to update.
3 Press the Power On/Off Button to reset. The radio runs the
usual power up operation if the software updates are
complete.
OR
The radio runs the Maintenance Mode if the updates are not
complete and repeat step 1.
Note: If SW INCOMPLETE appears, use Flashport Recovery
Tool to update the control heads before you power on
the radio again.
