Motorola GP series User Manual

PCB/Schematic Diagrams and Parts List: Keypad 2-7
3.2 PCB 8480574Z06 - Parts List
Circuit
Ref
Motorola
Part No.
Description
C610 2113743N50 100 PF 5% COG
C611 2113743N50 100 PF 5% COG
C612 2113743N50 100 PF 5% COG
C613 2113743N50 100 PF 5% COG
C615 2113743N50 100 PF 5% COG
C616 2113743N50 100 PF 5% COG
C618 2113743N50 100 PF 5% COG
C619 2113743N50 100 PF 5% COG
C620 2113743N50 100 PF 5% COG
C621 2113743N50 100 PF 5% COG
C622 2113743N50 100 PF 5% COG
C630 2113743N43 51.0 PF 5% COG
C631 2113743N50 100 PF 5% COG
C632 2113743N43 51.0 PF 5% COG
C633 2113743N50 100 PF 5% COG
C634 2113743N43 51.0 PF 5% COG
C635 2113743N50 100 PF 5% COG
C636 2113743N43 51.0 PF 5% COG
C637 2113743N50 100 PF 5% COG
C638 2113743N43 51.0 PF 5% COG
C639 2113743N50 100 PF 5% COG
C640 2113743N43 51.0 PF 5% COG
C641 2113743N50 100 PF 5% COG
C642 2113743N43 51.0 PF 5% COG
C643 2113743N50 100 PF 5% COG
C644 2113743N43 51.0 PF 5% COG
C645 2113743N50 100 PF 5% COG
C646 2113743N50 100 PF 5% COG
C647 2113743N43 51.0 PF 5% COG
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
E634 2480640Z01 C/IND BK1005HM471 BEAD
E637 2480640Z01 C/IND BK1005HM471 BEAD
E638 2480640Z01 C/IND BK1005HM471 BEAD
E639 2480640Z01 C/IND BK1005HM471 BEAD
E640 2480640Z01 C/IND BK1005HM471 BEAD
E641 2480640Z01 C/IND BK1005HM471 BEAD
E642 2480640Z01 C/IND BK1005HM471 BEAD
E643 2480640Z01 C/IND BK1005HM471 BEAD
E644 2480640Z01 C/IND BK1005HM471 BEAD
E645 2480640Z01 C/IND BK1005HM471 BEAD
J601 0980521Z01 ZIF VERTICAL,40 PIN
J602 0905505Y03 ZIF HORIZONTAL
Q601 4805128M67 SOT STR RH LOW PROFILE
MMBT
Q602 4880214G02 TSTR MMBT3904
Q603 4880214G02 TSTR MMBT3904
R601 0662057V20 51K 1% 1/16W
R602 0662057V20 51K 1% 1/16W
R603 0662057V05 13K 1% 1/16W
R604 0662057V11 22K 1% 1/16W
R605 0662057V18 43K 1% 1/16W
R606 0662057V30 130K 1% 1/16W
R607 0662057V05 13K 1% 1/16W
R608 0662057V11 22K 1% 1/16W
R609 0662057V18 43K 1% 1/16W
R610 0662057V30 130K 1% 1/16W
R611 0662057N16 51K 5% 20X40
R612 0662057N41 560K 5% 20X40
R613 0662057N47 1.0 MEG 5% 20X40
R614 0662057M01 0 5% 20X40
R617 0662057M01 0 5% 20X40
R618 0662057M74 1000 5% 20X40
R619 0662057M74 1000 5% 20X40
R620 0662057M74 1000 5% 20X40
R621 0662057M74 1000 5% 20X40
R622 0662057M74 1000 5% 20X40
R623 0662057M74 1000 5% 20X40
R626 0662057M01 0 5% 20X40
R627 0662057M01 0 5% 20X40
Circuit
Ref
Motorola
Part No.
Description
R631 0662057M01 0 5% 20X40
R632 0662057N23 100K 5% 20X40
R633 0662057N23 100K 5% 20X40
R646 0662057N23 100K 5% 20X40
R647 0662057M85 3000 5% 20X40
R648 0662057N23 100K 5% 20X40
R649 0662057N15 47K 5% 20X40
U602 5102463J49 COMPARATOR CMOS
LM7211
8480574Z06 BOARD, P.C. KEYPAD
Circuit
Ref
Motorola
Part No.
Description
