3-24
MS-6728 ATX Mainboard
On-Chip ATA(s) Operate Mode
This setting allows you to detemine how the RAID controller on the
south bridge is going to switch to SATA controller. Legacy Mode means
you may use the traditional 14 and 15 IRQs, while Native Mode means
you may use all the available IRQs. Setting options: Legacy Mode, Native
Mode.
ATA Configuration
The field lets you to configure the available ATA controller.Setting
options: Disabled, P-ATA Only, S-ATA Only, P-ATA+S-ATA.
S-ATA Keep Enabled
This item is available for you to enable/disable the onboard S-ATA.
Setting options: Yes, No.
P-ATA Keep Enabled
This item is available for you to enable/disable the onboard P-ATA.
Setting options: Yes, No.
P-ATA Channel Selection
This item is available for you to select the parellel ATA channel.
Setting options: Primary, Secondary, Both.
Combined Mode Option
This item is available for you to select the combined mode of the ATA
controllers. Setting options: P-ATA 1st Channel, S-ATA 1st Channel.
S-ATA Ports Definition
This allows you to set the boot sequence of serial ATA ports.
Configure S-ATA as RAID
This item is available for you to configure S-ATA as onboard RAID.
Setting: Yes, No.
C.S.A Gigabit Ethernet
This is used to set the C.S.A. Gigabit Ethernet. Setting: Auto, Disabled.
Onboard 1394 Device
This setting is used to enable/disable the onboard IEEE 1394 controller. Setting
options: Disabled, Enabled.
