MSI 870S-G46 series User Manual

2-8
Hardware Setup
Power Supply
ATX 24-pn Power Connector: JPWR1
Ths connector allows you to connect an ATX 24-pn power supply. To connect the ATX
24-pn power supply, make sure the plug of the power supply s nserted n the proper
orentaton and the pns are algned. Then push down the power supply 󰘰rmly nto the
connector.
You may use the 20-pn ATX power supply as you lke. If you’d lke to use the 20-pn
ATX power supply, please plug your power supply along wth pn 1 & pn 13.
13.+3.3
V
1.+3.3
V
14.-12V
2.+3.3
V
15.Ground
3
.Ground
16.PS-ON
#
4.+5
V
17.Ground
5
.Ground
18.Ground
6.+5
V
19.Ground
7
.Ground
22.+5
V
10.+12V
20.Res
8.PW
R O
K
23.+5
V
11
.+12V
21.+5
V
9.5VSB
24.Ground
12.+3.3
V
ATX 8-pn Power Connector: JPWR2
Ths connector s used to provde +12V power.
7.+12V
3.Ground
5.+12V
1.
Ground
8.+12V
4
.Ground
6.+12V
2
.Ground
Important
Make sure that all the connectors are connected to proper ATX power supples to en-
sure stable operaton of the manboard.

MSI 870S-G46 series Specifications

General

Socket	AM3
Form Factor	ATX
Max Memory	16GB
PCI Express x1 Slots	2
Max. LAN Speed	10/100/1000 Mbps
Audio Ports	6
Memory Slots	4
Memory Support	DDR3
PCI Express x16 Slots	1
SATA Ports	6
USB Ports	12
LAN Chipset	Realtek 8111E
PS/2	1
