MSI 890GXM-G65 series User Manual

Gettng Started ▍
MS-7642
1-3
Gettng Started ▍
MS-7642
Connectors
Back panel
1 Optcal S/PDIF-Out port
1 PS/2 keyboard/ mouse combo port
1 VGA port
1 DVI-D port **
4 USB 2.0 ports
2 USB 3.0 blue ports
1 HDMI port **
1 E-SATA port
1 LAN port
6 󰘱exble audo ports
**(The HDMI and DVI-D ports can not work smultaneously)
On-Board
4 USB 2.0 connectors
1 Chasss Intruson connector
1 Seral port connector
1 Parallel port connector
1 CD-In connector
1 Front Panel Audo connector
1 S/PDIF-out connector
1 TPM Module connector
Slots
2 PCI Express 2.0 x16 slots
when you nstall two expanson cards nto both PCIE x16 slots, the PCI_E1 &
PCI_E2 lanes wll run wth x8 speed.
f you ntend to nstall only one expanson card, please nstall t nto PCI_E1 slot,
and the PCI_E1 lane wll run wth x16 speed
1 PCI Express x1 slot
1 PCI slot, supports 3.3V/ 5V PCI bus Interface
Form Factor
Mcro-ATX (24.4cm X 24.4 cm)
Mountng
8 mountng holes
■
-
-
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
-
■
-
-
■
■
■
■

MSI 890GXM-G65 series Specifications

General

Brand	MSI
Model	890GXM-G65 series
Category	Motherboard
Language	English
