Introductions
Left Side View
1. Power Connector
This connector is to connect the AC/DC adapter and supply power for the notebook.
2. Thunderbolt port (Type-C) (optional)
• Always plug the provided AC/DC adapter that comes with the package to either
port to supply power to the notebook and charge the battery pack.
• Thunderbolt™ 4 supports USB 4.0, PCIe, HDMI, DisplayPort connection; 4K
display monitor output; up to 40Gbps data rate; and 5V/3A portable charging
power output (follow the Intel
®
Thunderbolt
TM
protocol specification).
3. Combo Audio Port
• A port for a headset, microphone, or headset with
microphone.
• The Combo Audio Port supports 4-Pole 3.5mm
headphone jack.
4. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
5. USB 3.2 Gen 1 Port
USB 3.2 Gen 1, the SuperSpeed USB, supports high-speed data transfer for the
connected devices, such as storage devices, hard drives, or video cameras.
