MSI Aegis 3 User Manual

iv
Upgrade and Warranty
Please note that certain components preinstalled in the product may be upgradable
or replaceable by user’s request� For any further information about the product users
purchased, please contact the local dealer� Do not attempt to upgrade or replace any
component of the product if you are not an authorized dealer or service center, since it
may cause the warranty void� It is strongly recommended that you contact the authorized
dealer or service center for any upgrade or replace service�
Acquisition of Replaceable Parts
Please be noticed that the acquisition of replaceable parts (or compatible ones) of
the product users purchased in certain countries or territories may be ful󰘰lled by the
manufacturer within 5 years at most since the product has been discontinued, depending
on the o󰘲cial regulations declared at the time. Please contact the manufacturer via
http://www�msi�com/support/ for the detailed information about the acquisition of spare
parts�
Technical Support
If a problem arises with your system and no solution can be obtained from the user’s
manual, please contact your place of purchase or local distributor� Alternatively, please
try the following help resources for further guidance� Visit the MSI website for technical
guide, BIOS updates, driver updates and other information via http://www�msi�com/
support/
Green Product Features
◙ Reduced energy consumption during use and stand-by
◙ Limited use of substances harmful to the environment and health
◙ Easily dismantled and recycled
◙ Reduced use of natural resources by encouraging recycling
◙ Extended product lifetime through easy upgrades
◙ Reduced solid waste production through take-back policy

MSI Aegis 3 Specifications

General

Bus type	DMI3
Tjunction	100 °C
Processor cache	9 MB
Processor cores	6
Processor model	i5-8400
System bus rate	8 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1151 (Socket H4)
Processor codename	Coffee Lake
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	65 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Maximum internal memory supported by processor	64 GB
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	2400 MHz
Maximum internal memory	32 GB
HDD size	2.5/3.5 \
HDD capacity	1000 GB
SSD capacity	128 GB
SSD interface	M.2
Storage media	HDD+SSD
Optical drive type	DVD Super Multi
Total storage capacity	1128 GB
Number of storage drives installed	2
Discrete graphics card	Yes
Number of execution units	23
On-board graphics card ID	0x3E92
Discrete graphics card model	NVIDIA® GeForce® GTX 1060
On-board graphics card model	Intel® UHD Graphics 630
Discrete graphics card memory	3 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Chassis type	Desktop
Product color	Black
Product type	PC
Motherboard chipset	Intel® B250
Operating system installed	Windows 10
Power supply	450 W
80 PLUS certification	80 PLUS Bronze
Cables included	AC
Scalability	1S
Processor ARK ID	126687
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2015C
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	376 mm
Width	170 mm
Height	433 mm
Weight	80500 g
Package weight	11200 g
