Specifications
Specifications
CPU
Support AMD
®
Ryzen™ 1
st
and 2
nd
Generation/ Ryzen™ with
Radeon™ Vega Graphics Processors for Socket AM4
Chipset AMD
®
B450 Chipset
Memory
y
4x DDR4 memory slots, support up to 64GB*

Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)

Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz
(by A-XMP OC MODE)
y
Dual channel memory architecture
y
Supports non-ECC UDIMM memory
y
Supports ECC UDIMM memory (non-ECC mode)
* Please refer www.msi.com for more information on compatible memory.
Expansion Slots
y 1x PCIe 3.0 x16 slot (PCI_E1)
 Supports x16 speed with AMD
®
Ryzen™ 1st and 2nd
Generation processors
 Supports x8 speed with AMD
®
Ryzen™ with Radeon
Vega Graphics processors
y 1x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
y 4x PCIe 2.0 x1 slots*
* PCI_E4 will run x1 speed when installing devices in PCI_E2/ PCI_E3/ PCI_E5
slot.
Onboard Graphics
y 1x VGA port, support a maximum resolution of 2048x1280
@60Hz,1920x1200 @60Hz
y 1x DVI-D port, support a maximum resolution of 1920x1200
@60Hz*
y 1x HDMI™ 1.4 port, supports a maximum resolution of
4096x2160 @30Hz, 2560x1600 @60Hz*
* Only support when using AMD
®
Ryzen™ with Radeon Vega Graphics Processors
* Maximum shared memory of 2048 MB
Multi-GPU y Supports 2-Way AMD
®
CrossFire™ Technology
LAN y 1x Realtek
®
8111H Gigabit LAN controller
Audio
y Realtek
®
ALC892 Codec
y 7.1-Channel High Definition Audio
Continued on next page

MSI B450 TOMAHAWK MAX Specifications

General

Form Factor	atx
Chipset	amd b450
Processor Socket	socket am4
Processor Compatibility	amd ryzen 3 2000 series, amd ryzen 5 2000 series, amd ryzen 7 2000 series, amd ryzen 3 3000 series, amd ryzen 5 3000 series, amd ryzen 7 3000 series, amd ryzen 3 4000 series, amd ryzen 5 4000 series, amd ryzen 7 4000 series, amd ryzen 7
Maximum Memory	64 gigabytes
Power Connector	24-pin main power connector, 8-pin atx12v connector
PCI Bus Slots	5
Memory Slots	4

Weight and Dimensions

Width	12 inches
