MSI G243CV User Manual

21
Specifications
Specifications
Monitor G243CV G274CV G323CV
Size 23.6 inch 27 inch 31.5 inch
Curvature Curve 1500R
Panel Type VA
Resolution 1920 x 1080 (FHD)
Aspect Ratio 16:9
Brightness 250 nits (typ.)
Contrast Ratio 3000:1 4000:1 3000:1
Refresh Rate 75Hz
Response Time
4ms (GTG)
1ms (MPRT)
I/O
∙ Headphone Jack x1
∙ HDMI Port x1
∙ DisplayPort Port x1
View Angles 178°(H) , 178°(V)
DCI-P3*/ sRGB 77% / 98%
Surface Treatment Anti-glare
Display Colors 16.7M 1.07b 16.7M
Monitor Power Options
12V
2.5A 12V 4A
External Power Supply
Model: SOY-
1200250-097
Model: YD-ZN1200400-A01
Power Input
100~240Vac,
50/60Hz, 0.75A
100~240Vac, 50/60Hz, 1.5A max
Power Output
12V
2.5A 12V 4A
Adjustment (Tilt) -5° ~ 20°
Adjustment (Swivel) -30° ~ 30°
Kensington Lock Yes

MSI G243CV Specifications

General

Panel type	VA
Color gamut	77 %
Pixel pitch	0.272 x 0.272 mm
Display diagonal	23.6 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Viewable size, vertical	293 mm
sRGB coverage (typical)	98 %
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60 cm
Viewable size, horizontal	521 mm
Digital vertical frequency	48 - 75 Hz
Digital horizontal frequency	52.8 - 90 kHz
Display brightness (typical)	250 cd/m²
HDMI version	1.4b
DisplayPort version	1.2a
Input current	2.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output voltage	12 V
Power consumption (standby)	- W
Package depth	140 mm
Package width	600 mm
Package height	400 mm
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Product color	Black
Market positioning	Gaming
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	184.7 mm
Width (with stand)	539.8 mm
Height (with stand)	413.4 mm
Depth (without stand)	74.2 mm
Height (without stand)	321.8 mm
