13
Professional
1st Level Menu 2nd Level Menu Description
Pro Mode Eco Use Up or Down Button to select and preview mode
effects.
Press the OK Button to confirm and apply your mode
type.
User
Anti-Blue
Movie
Office
sRGB
Low Blue Light OFF Low Blue Light protects your eyes against blue light.
When enabled, Low Blue Light adjusts the screen color
temperature to a more yellow glow.
When Pro Mode is set to Anti-Blue, it is mandatory to
enable Low Blue Light.
ON
HDCR OFF HDCR enhances image quality by increasing the
contrast of images.
Activating HDCR will affect:
Affected Function Function Status
» Brightness Unable to select
» MPRT Set to OFF
ON
MPRT OFF Activating MPRT will affect:
Affected Function Function Status
» Response Time
» Brightness
Unable to select
» Adaptive-Sync
» HDCR
Set to OFF
MPRT is available when the refresh rate is over 85Hz.
ON
Image Enhancement OFF Image Enhancement enhances image edges to improve
their acutance.
Weak
Medium
Strong
Strongest
