MSI G45 User Manual

MS-7519 Mainboard
2-8
Installing Memory Modules
1. The memory module has only one notch on the center and will only fit in the right
orientation.
2. Insert the memory module vertically into the DIMM slot. Then push it in until the
golden finger on the memory module is deeply inserted in the DIMM slot. The plastic
clip at each side of the DIMM slot will automatically close when the memory module
is properly seated.
3. Manually check if the memory module has been locked in place by the DIMM slot
clips at the sides.
Important
You can barely see the golden finger if the memory module is properly inserted
in the DIMM slot.
Volt
Notch

MSI G45 Specifications

General

Form Factor	ATX
Memory Slots	4
SATA Ports	6
Audio Channels	7.1
PS/2	1
eSATA	1
Audio Ports	6
RAID Support	Yes
SATA RAID	0/1/5/10
Max. LAN Speed	10/100/1000 Mbit/s
S/PDIF Out	1
Dimensions	30.5 x 24.4 cm
Power Pin	24-pin ATX, 8-pin ATX 12V
Multi-GPU Support	ATI CrossFireX
