User's Manual
2-10 2-11
Bottom Side View
1. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
2. Woofer Speakers
The woofer speaker is to reproduce low-pitched audio frequency.
3. Stereo Speakers
This notebook may be equipped with built-in stereo speakers which deliver the high
quality sound, and supports the HD audio technology.
4. Battery Reset Hole
Whenever the system firmware (EC) is upgraded or the system hangs, please 1)
power off the notebook; 2) remove the AC power; 3) use a straightened paperclip to
insert this hole for 10 sec; 4) connect the AC power; 5) power on the notebook.
