MSI GP76 Leopard User Manual

2-8 2-9
Rear Side View
1. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
2. Thunderbolt (Type-C) port (optional)
• Thunderbolt™ 4 supports USB4, PCIe, HDMI, DisplayPort connection; 8K display
monitor output; up to 40Gbps transfer rate.
• Supports maximum 5V/3A portable charging power output when AC power is
connected. However, the maximum portable charging power limitation may up to
5V/1.5A while only battery DC power is connected. (follow the Intel Thunderbolt
protocol and USB Power Delivery specification).
3. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
4. Mini-DisplayPort
The Mini-DisplayPort is a miniaturized version of the DisplayPort, with a suitable
adapter, the Mini-DisplayPort may be used to drive displays with a VGA, DVI or HDMI
interface.
5. RJ-45 Connector
The Ethernet connector, with optionally supported transmitting rate of
10/100/1000/2500 megabits per second, is used to connect a LAN cable for network
connection.
6. Power Connector
This connector is to connect the AC/DC adapter and supply power for the notebook.

MSI GP76 Leopard Specifications

General

Operating system installed	FreeDOS
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Combo headphone/mic port	Yes
Mini DisplayPorts quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network connection	No
WLAN controller manufacturer	Killer
Front camera HD type	HD
Video capturing speed	30 fps
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 3070
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
SSD capacity	1000 GB
Storage media	SSD
Battery capacity	65 Wh
Number of battery cells	4
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	3200 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 8 GB
Motherboard chipset	Intel HM570
Processor cache	24 MB
Processor cores	8
Processor model	i7-11800H
Processor family	Intel® Core™ i7
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor boost frequency	4.6 GHz
Display diagonal	17.3 \
Maximum refresh rate	240 Hz
Pointing device	Touchpad
Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Gaming
AC adapter power	280 W

Weight and Dimensions

Depth	284 mm
Width	397 mm
Height	25.9 mm
Weight	2900 g
