MSI GT60 User Manual

Preface
1-2
Contents
Chapter 1: Preface
Content ........................................................................... 1-2
Regulations and Statements......................................... 1-4
FCC-B Radio Frequency Interference Statement....... 1-4
FCC Conditions .......................................................... 1-4
CE Conformity ............................................................ 1-4
Battery Regulations .................................................... 1-5
WEEE Statement ........................................................ 1-5
Safety Instructions ........................................................ 1-6
Optical Device Drive Notice .......................................... 1-8
Trademarks..................................................................... 1-8
Reversion History .......................................................... 1-8
Chapter 2: Introductions
Manual Map .................................................................... 2-2
Unpacking....................................................................... 2-2
Product Overview .......................................................... 2-3
Top-Open View ........................................................... 2-3
Front Side View .......................................................... 2-7
Right Side View .......................................................... 2-9
Left Side View ............................................................2-11
Rear Side View ......................................................... 2-12
Bottom Side View ..................................................... 2-13
Specification ................................................................ 2-14
Chapter 3: Getting Started
Begin to Use the Notebook........................................... 3-2
Power Management ....................................................... 3-3
AC Power.................................................................... 3-3
Battery Power ............................................................. 3-3
Power Management in Windows OS .......................... 3-7

MSI GT60 Specifications

General

Bus type	DMI
Tjunction	105 C °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-3610QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	Socket G2
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	23
Maximum number of SMP processors	1
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM77 Express
Internal memory	12 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	Blu-Ray RW
Card reader integrated	Yes
Total storage capacity	750 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC, SDXC, xD
LED backlight	-
Display diagonal	15.6 \
Native aspect ratio	16:9
Volume control	Digital
Graphics card family	Intel, NVIDIA
Ethernet interface type	Gigabit Ethernet
Number of products included	1 pc(s)
On-board graphics card ID	0x166
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	THX TruStudio Pro
Speakers manufacturer	Dynaudio
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Keyboard layout	QWERTY
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Gaming
Processor ARK ID	64899
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery life (max)	- h
Number of battery cells	9
AC adapter power	180 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V

Weight and Dimensions

Weight	3400 g
Depth (imperial)	14.97 \
Width (imperial)	10.24 \
Height (imperial)	1.77 \
