MSI H170M ECO User Manual

4
Specifications
Continued from previous page
Internal
Connectors
y 1x 24-pin ATX main power connector
y 1x 4-pin ATX 12V power connector
y 6x or 4x SATA 6Gb/s connectors (optional)
y 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
y 1x USB 3.1 Gen1 connector (supports additional 2 USB 3.1
Gen1 ports)
y 1x 4-pin CPU fan connector
y 2x 4-pin system fan connectors
y 1x Front panel audio connector
y 2x Front panel connectors
y 1x TPM module connector
y 1x Serial port connector
y 1x Parallel port connector
y 1x Chassis Intrusion connector
y 1x Clear CMOS jumper
I/O Controller NUVOTON NCT6793D Controller Chip
Hardware
Monitor
y CPU/System temperature detection
y CPU/System fan speed detection
y CPU/System fan speed control
Form Factor
y ATX Form Factor
y 9.6 in. x 8.1 in. (24.3 cm x 20.6 cm)
BIOS Features
y 1x 64 Mb flash
y UEFI AMI BIOS
y ACPI 5.0, PnP 1.0a, SM BIOS 2.8
y Multi-language
Software
y Drivers
y LIVE UPDATE 6
y FAST BOOT
y SUPER CHARGER
y M-CLOUD
y Intel
®
Small Business Basics
y Norton
™
Security
y Google Chrome
™
,Google Toolbar, Google Drive
y ECO Center Pro
y ECO Meter

MSI H170M ECO Specifications

General

Form Factor	Micro ATX
Socket	LGA 1151
Chipset	Intel H170
Memory Slots	4
Max Memory	64 GB
PCI Express Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
Storage Interface	6 x SATA 6Gb/s
USB Ports	6 x USB 3.1 Gen1, 6 x USB 2.0
Audio	Realtek ALC887
Memory Speed	DDR4 2133
LAN	Realtek RTL8111H
Video Outputs	1 x DVI-D, 1 x HDMI, 1 x VGA
