MSI H55M-E23 User Manual

Hardware Setup
MS-7636
Chapter 2
2-3
Hardware Setup
MS-7636
Chapter 2
Screw Holes
When you nstall the manboard, you have to place the manboard nto the chasss n the
correct drecton. The locatons of screws holes on the manboard are shown as below.
Refer above pcture to nstall stando󰘯s n the approprate locatons on chasss and then
screw through the manboard screw holes nto the stando󰘯s.
Important
To prevent damage to the manboard, any contact between the manboard crcut and
chasss or unnecessary stando󰘯s mounted on the chasss s prohbted.
Please make sure there s no metal components placed on the manboard or wthn
the chasss that may cause short crcut of the manboard.
•
•
Screw holes
The sde has to
toward the rear,
the poston for
the I/O sheld of
the chasss.
