Chapter 1
1-4Getting Started
Motherboard Specications
CPU
Support
4th Generation Intel
®
Core i7 / Core i5 / Core i3 / Pentium
®
/
Celeron
®
processors for LGA 1150 socket
Chipset Intel
®
Z87 Express Chipset (Z87-G43)
Intel
®
H87 Express Chipset (H87-G43)*
Intel
®
B85 Express Chipset (B85-G43)*
* Supports Intel
®
SBA.
Memory
Support
4x DDR3 memory slots supporting up to 32GB
Supports DDR3 3000(OC)/ 2800(OC)/ 2666(OC)/ 2600(OC)/
2400(OC)/ 2200(OC)/ 2133(OC)/ 2000(OC)/ 1866(OC)/ 1600/ 1333/
1066 MHz
OC is for Z87-G43 only.
Dual channel memory architecture
Supports non-ECC, un-buered memory
Supports Intel
®
Extreme Memory Prole (XMP)
-
Expansion
Slots
1x PCIe 3.0 x16 slot
1x PCIe 2.0 x16 slot
Supports up to PCIe 2.0 x4 speed.
2x PCIe 2.0 x1 slots
3x PCI slots
-
Onboard
Graphics
1x VGA port, supporting a maximum resolution of 1920x1200 @
60Hz
1x HDMI
®
port, supporting a maximum resolution of
4096x2160@24Hz, 24bpp/ 2560x1600@60Hz, 24bpp/
1920x1080@60Hz, 36bpp
1x DVI-D port, supporting a maximum resolution of 1920x1200 @
60Hz
Multi-GPU
Support
Supports 2-Way AMD CrossFire
TM
Technology*
* Supports Windows 7 and Windows 8.
Storage Intel Z87/ H87/ B85 Express Chipset
6x SATA 6Gb/s ports (SATA1~6) (Z87-G43/ H87-G43)
4x SATA 6Gb/s ports (SATA1~4) (B85-G43)
2x SATA 3Gb/s ports (SATA5~6) (B85-G43)
Supports RAID 0, RAID1, RAID 5 and RAID 10 (For Z87-G43/
H87-G43)
Supports Intel Smart Response Technology, Intel
®
Rapid Start
Technology and Intel
®
Smart Connect Technology*
* Supports Intel Core processors on Windows 7 and Windows 8.
-
-
-
-
-
USB Intel Z87/ H87/ B85 Express Chipset
4x USB 3.0 ports (2 ports on the back panel, 2 ports available
through the internal USB connectors)
10x USB 2.0 ports (6 ports on the back panel, 4 ports available
through the internal USB connectors)
-
-
Audio Realtek
®
ALC892 Codec
7.1-Channel High Denition Audio
-
LAN 1x Realtek
®
8111E Gigabit LAN controller
To Next Page
