MSI MEG Ai1000P PCIE5 User Manual

2
Specifications
1300W
AC Input
100-240V~, 15A Max, 50-60Hz
For use in China only: 200-240V~, 8A, 50-60Hz
DC Output
(Single-rail,
default)
+5V +3.3V +12V -12V +5Vsb
25A 25A 108.33A 0.3A 3A
DC Output
(Multi-rail*)
+5V +3.3V +12V1 +12V2 +12V3 +12V4 +12V5 -12V +5Vsb
25A 25A 40A 50A 50A 50A 50A 0.3A 3A
Total Power
130W 1300W 3.6W 15W
1300W
1000W
AC Input
100-240V~, 15A Max, 50-60Hz
For use in China only: 200-240V~, 8A, 50-60Hz
DC Output
(Single-rail,
default)
+5V +3.3V +12V -12V +5Vsb
22A 22A 83.33A 0.3A 3A
DC Output
(Multi-rail*)
+5V +3.3V +12V1 +12V2 +12V3 +12V4 +12V5 -12V +5Vsb
22A 22A 40A 50A 50A 50A 50A 0.3A 3A
Total Power
130W 1000W 3.6W 15W
1000W
* Please refer to “Software Control and Monitoring” section to download and install
MSI Center to activate 12V multi-rail output.

MSI MEG Ai1000P PCIE5 Specifications

General

Cabling type	Fully-Modular
Motherboard power connector	24-pin ATX
ATX Power connector (24-pin)	Yes
Number of SATA power connectors	12
PCI Express power connectors (6+2 pin)	8
Peripheral (Molex) power connectors (4-pin)	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Combined power (+12V)	1000 W
Combined power (+3.3V)	120 W
Combined power (+5Vsb)	15 W
Max output current (+12V)	83.33 A
Max output current (-12V)	0.3 A
Power protection features	Over current, Over power, Over voltage, Short circuit, Under voltage
Max output current (+3.3V)	22 A
Max output current (+5Vsb)	3 A
Power Factor Correction (PFC) type	Active
Fan diameter	120 mm
Product color	Black
Number of fans	1 fan(s)
Purpose	PC
Noise level	- dB
80 PLUS certification	80 PLUS Gold
Power supply unit (PSU) form factor	ATX
Harmonized System (HS) code	84733020
Package type	Box

Weight and Dimensions

Depth	160 mm
Width	150 mm
Height	86 mm
Weight	- g
