5
Specifications
Specifications
CPU
∙ Supports 10th Gen Intel® Core ™ Processors, 11th Gen
Intel® Core ™ Processors, Pentium® Gold and Celeron®
Processors*
∙ Processor socket LGA1200
* Please go to intel.com for compatibility information
Chipset
Intel® Z590 Chipset
Memory
∙ 4x DDR4 memory slots, support up to 128GB*
∙ Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel®
CPU (by JEDEC & POR)*
∙ Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen
Intel® CPU (by JEDEC & POR)*
∙ Max overclocking frequency:
▪ 1DPC 1R Max speed up to 5600 MHz
▪ 1DPC 2R Max speed up to 4800+ MHz
▪ 2DPC 1R Max speed up to 4400+ MHz
▪ 2DPC 2R Max speed up to 4000+ MHz
∙ Supports Dual-Channel mode
∙ Supports non-ECC mode, un-buffered memory
∙ Supports Intel® Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on compatible memory.
Expansion Slot
∙ 1x PCIe x16 slot (PCI_E2, from CPU)
▪ Supports up to PCIe 4.0 x16 with11th Gen CPU*
▪ Supports up to PCIe 3.0 x16 with10th Gen CPU*
∙ 1x PCIe 3.0 x4 slot (PCI_E4, from Z590 chipset)**
∙ 2x PCIe 3.0 x1 slots (from Z590 chipset)
* PCI_E2 will only support x8 speed, when M2_2 and M2_3 are from CPU by BIOS
selection.
** PCI_E4 and M2_4 share the same bandwidth, if you want to use both of them
simultaneously, the PCI_E4 will only support x1 speed and the M2_4 will only
support x2 speed. But if you want to install and enable the graphics card in
PCI_E4 slot, the M2_4 slot should be empty.
Multi-GPU ∙ Supports 2-Way AMD® CrossFire™ Technology
Onboard Graphics
∙ 1x HDMI 2.0b with HDR port, supports a maximum
resolution of 4K 60Hz *
/
**
* Available for the processor with integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
Continued on next page
