MSI Modern MD272P User Manual

7
Getting Started
1
OSD Keys
2
Power Button / Power LED
Lit in white after the monitor is turned on. If no signal input, the LED will
turn into orange. Lit in orange when the monitor is in Stand-by mode.
3
Power Jack
4
USB Type-C Port
This port supports DisplayPort Alternate (DP Alt) Mode and up to 20V/3.25A
(65W) power delivery.
5
DisplayPort
6
HDMI Port
7
Headphone Jack
8
USB 2.0 Type-B Upstream Port
For USB Upstream Cable.
⚠
Important
Check the package for USB
Upstream Cable and connect it
to the PC and monitor. Once this
cable is connected, the USB Type-A
Downstream Ports on the monitor
will be ready for use.
To PC
To Monitor
9
USB 2.0 Type-A Port
10
Kensington Lock

MSI Modern MD272P Specifications

General

Color depth	8 bit
Pixel pitch	0.3114 x 0.3114 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LCD
Maximum refresh rate	75 Hz
Viewable size, vertical	336.312 mm
sRGB coverage (typical)	100 %
Contrast ratio (dynamic)	100000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	597.888 mm
Digital vertical frequency	8 - 75 Hz
Digital horizontal frequency	30 - 112 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Input current	5.79 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
AC adapter output voltage	19 V
Power consumption (standby)	- W
Package type	Box
Package depth	464 mm
Package width	893 mm
Package height	167 mm
Package weight	8100 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 20 °
Height adjustment	110 mm
Cable lock slot type	Kensington
Panel mounting interface	75 x 75 mm
Product color	Black
Market positioning	Business
Compatibility	PC, Mac, PS5™, PS4™, Xbox, Mobile, Notebook
RMS rated power	2 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	200.81 mm
Width (with stand)	613.5 mm
Height (with stand)	401.5 mm
Weight (with stand)	58005850 g
